The graphical symbols provided are for use on operator controls and other displays on fire and rescue apparatus. These symbols are appropriate for vehicles designed to meet NFPA 1901 Standard for Automotive Fire Apparatus, NFPA 1906 Standard for Wildland Apparatus, and NFPA 414 Standard for Airport Rescue and Fire Fighting Vehicles.

Download the pdf file posted below to review Chapters 1-7 which cover: the scope, a list of reference documents used, definitions, a general overview, colors, a process for symbol adaption, and rules of use. Chapters 8-18 cover the complete list of the graphical symbols.

The artwork and information in this area gives the fire and rescue community an option for labeling common controls with a graphical representation of their function. This can be either in place of, or in addition to, the traditional text description. Some symbols have been adopted from already established sources, and many of the symbols are identical or similar to those being developed for use in Europe.

Symbol Number Download Symbol Graphical Symbol Symbol Description/Application Reference Number Reference Standard
16.01

Battery

0247 ISO 7000
16.02

Ammeter

3.2.5 CEN 15989
16.03

Generator

1153 ISO 7000
16.04

Generator Pre-Heater

None
16.05

Voltmeter

3.2.4 CEN 15989
16.06

Electrical Outlet
Replace “N” with the number of the circuit that it is powered from. Replace the xxx with the voltage and xx with the amperage of the circuit.

None
16.07

Electrical Cord Reel Outlet
Replace “N” with the number of the circuit that it is powered from. Replace the xxx with the voltage and xx with the amperage of the circuit.

None
16.08

Battery Disconnect;
Battery Shut-Off

2063 3.5.5 ISO 7000 CEN 15989
16.09

Intercom

None
