The following graphical symbols are for use on operator controls and other displays on fire and rescue apparatus. These symbols are appropriate for vehicles designed to meet NFPA 1901 Standard for Automotive Fire Apparatus, NFPA 1906 Standard for Wildland Apparatus, and NFPA 414 Standard for Airport Rescue and Fire Fighting Vehicles.

The artwork and information in this area gives the fire and rescue community an option for labeling common controls with a graphical representation of their function. This can be either in place of, or in addition to, the traditional text description. Some symbols have been adopted from already established sources, and many of the symbols are identical or similar to those being developed for use in Europe.

Symbol Number Download Symbol Graphical Symbol Symbol Description/Application Reference Number Reference Standard
8.01

Water

0536 ISO 7000
8.02

Foam Concentrate

3.3.2 CEN 5989:2010
8.03

Foam Solution

3.3.3 CEN 5989:2010
8.04

Powder

3.3.4 CEN 5989:2010
8.05

Compressed Air Foam (CAF) Wet

None
8.06

Compressed Air Foam (CAF) Dry

None
8.07

Halotron

None
9.01

On / Start Use independently or in
conjunction with other symbols. Do
not use as a graphical element in
developing combined symbols per
Clause 4.5

5007 IEC 60417
9.02

Off / Stop Use independently or in
conjunction with other symbols. Do
not use as a graphical element in
developing combined symbols per
Clause 4.5

5008 IEC 60417
9.03

On and Off Use independently or in
conjunction with other symbols. Do
not use as a graphical element in
developing combined symbols per
Clause 4.5

5010 IEC 60417
